The vertical method is easy to implement but is difficult to maintain over time as the business grows. In a vertically integrated system, sub-systems are combined into ‘information silos’ in accordance with their functions. The sub-systems in these silos operate independently, without any communication with other silos.

Pros

• Simple - This is a good method for companies lacking a strong IT team because it doesn’t require much coding knowledge.
• Easy to create - No super-genius coding skills needed to bring this integration to life.
• Isolated subsystems - Each subsystem sends individual requests to other subsystems, rather than being connected.

Cons

• Too rigid - Vertical integration does not allow for any flexibility or change.
• More silos must be created over time - For each new subsystem, a new silo must be created.
• Hard to manage - When there are too many information silos in the system, it gets cluttered and slow.

In contrast to vertical system integration, the horizontal method’s purpose is to allow communication between subsystems. This is done by creating an Enterprise Service Bus (ESB). The ESB acts as a translator and connector between the subsystems. Only one interface is needed for each subsystem, in order to communicate with the ESB. A benefit of this method is that when making changes, to other subsystems, only the ESB needs to change along with it, rather than the entire system. However, because the ESB is the central hub of the operation, any problems within the subsystems or the ESB itself can bring the whole process down.

Pros

• More flexible - Subsystems can send and receive requests through the ESB with ease.
• Fewer changes - Changes only need to be made to the ESB if a subsystem changes.
• Subsystem communication - Unlike vertical integration, the subsystems can connect with every other subsystem.

Cons

• High risk of system error - If something goes wrong with one subsystem or the ESB, it could affect the entire system.
• Lower communication speed - The ESB may perform slowly because of all the data it’s processing.
• Needs a specialized system - The ESB needs to be specially made for your system.

Known by a few different names, the star, spaghetti, or point-to-point method operates by connecting each subsystem independently to all of the other subsystems. This allows for more communication without the need for an ESB. But, if one subsystem needs to be changed, the others do as well. This is a great method when there aren’t too many subsystems in the system.

Pros

• Autonomous - Communication happens automatically.
• All subsystems are connected - Each subsystem is individually connected to every other subsystem.
• Faster communication - Without the bulky ESB, data moves faster throughout the system.

Cons

• All subsystems must change when one does - Otherwise they won’t be able to communicate properly.
• Very complex - A lot of planning must be done to ensure that each subsystem can connect properly to the others.
• High risk of problems when there are too many connections - The more subsystems there are, the higher the likelihood of there being problems.

When using this type of integration approach, a new data language is made. As the language of Esperanto, it is a universal format that all the subsystems use to transfer and process data with one another. This method is used to avoid having more than one adaptor for every subsystem within a system.

Pros

• Excellent translation - All subsystems are ‘fluent’ and can communicate seamlessly.
• Automated - No need to manually make requests.
• Systems do not need to work together - Each subsystem operates independently.

Cons

• High coding skill needed - This is a complex method, that takes a ton of coding skill.
• Risk of initial problems - While setting up, a lot of issues tend to arise with the data format.
